UNC/NF HSS Machine Screw Tap & Die Set [33pc] 0-80NF to 5-44NF

Availability:
If in stock (Please see below price for current stock level) - Ships same day if ordered between Monday-Friday & before 3.30PM Victorian time.
Shipping:
Calculated at Checkout
  • HSS Machine Screw Thread 33pc Tap & Die Set. Unified Threads. 0-80NF to 5-44NF. 22 Taps & 11 Dies. Supplied with a Taper & Plug tap & matching Button Die for 11 different sizes. Supplied by LPR Toolmakers an Australia owned family business that imports high quality HSS Machine Screw thread tap & dies. Shipped from Melbourne, Victoria.
  • HSS Machine Screw Thread 33pc Tap & Die Set. Unified Threads. 0-80NF to 5-44NF. 22 Taps & 11 Dies. Supplied with a Taper & Plug tap & matching Button Die for 11 different sizes. Supplied by LPR Toolmakers an Australia owned family business that imports high quality HSS Machine Screw thread tap & dies. Shipped from Melbourne, Victoria.
  • HSS Machine Screw Thread 33pc Tap & Die Set. Unified Threads. 0-80NF to 5-44NF. 22 Taps & 11 Dies. Supplied with a Taper & Plug tap & matching Button Die for 11 different sizes. Supplied by LPR Toolmakers an Australia owned family business that imports high quality HSS Machine Screw thread tap & dies. Shipped from Melbourne, Victoria.
  • HSS Machine Screw Thread 33pc Tap & Die Set. Unified Threads. 0-80NF to 5-44NF. 22 Taps & 11 Dies. Supplied with a Taper & Plug tap & matching Button Die for 11 different sizes. Supplied by LPR Toolmakers an Australia owned family business that imports high quality HSS Machine Screw thread tap & dies. Shipped from Melbourne, Victoria.
  • HSS Machine Screw Thread 33pc Tap & Die Set. Unified Threads. 0-80NF to 5-44NF. 22 Taps & 11 Dies. Supplied with a Taper & Plug tap & matching Button Die for 11 different sizes. Supplied by LPR Toolmakers an Australia owned family business that imports high quality HSS Machine Screw thread tap & dies. Shipped from Melbourne, Victoria.
  • HSS Machine Screw Thread 33pc Tap & Die Set. Unified Threads. 0-80NF to 5-44NF. 22 Taps & 11 Dies. Supplied with a Taper & Plug tap & matching Button Die for 11 different sizes. Supplied by LPR Toolmakers an Australia owned family business that imports high quality HSS Machine Screw thread tap & dies. Shipped from Melbourne, Victoria.
  • HSS Machine Screw Thread 33pc Tap & Die Set. Unified Threads. 0-80NF to 5-44NF. 22 Taps & 11 Dies. Supplied with a Taper & Plug tap & matching Button Die for 11 different sizes. Supplied by LPR Toolmakers an Australia owned family business that imports high quality HSS Machine Screw thread tap & dies. Shipped from Melbourne, Victoria.
MSRP: $699.95
$489.95
— You save $210.00

Description

NC/NF Machine Screw Tap & Die Set [33pc]

MADE FROM HSS - 22 Taps & 11 Button Dies

  Features all the hard to find smaller machine screw sizes: 0-80NF to 5-44NF



11 Tap & Die sizes included in this kit - Save huge $$ then buying singularly



0-80NF, 1-64NC, 1-72NF, 2-56NC, 2-64NC, 3-48NC, 3-56NF, 4-40NC, 4-48NF, 5-40NC, 5-44NF



These are the very small UNF & UNC American threads that you normally only see in books, but they are extensively used for small machine screws in the industry.

Each tap size comes in a set of 2 which include a Taper and Plug type tap.

All the dies are of 13/16" OD

Each Tap & Die are made to ISO standards - the quality of the finish and performance of these taps & dies are second to none



MACHINE SCREW TAP & DIE SIZES WE STOCK - HIGHLIGHTED GREEN ARE THE SIZES YOU WILL RECIEVE IN THIS KIT

Thread SizeThreads per Inch (TPI)Die ODTap Drill SizeDecimal Drilled Hole
0-80 (NF) 80 13/16″ 3/64″ .0469″
1-64 (NC) 64 13/16″ #53 .0595″
1-72 (NF) 72 13/16″ #53 .0595″
2-56 (NC) 56 13/16″ #50 .0700″
2-64 (NC) 64 13/16" #50 .0700"
3-48 (NC) 48 13/16″ #47 / 5/64″ .0785″
3-56 (NF) 56 13/16″ #45 .0820″
4-40 (NC) 40 13/16″ #43 / 3/32″ .0890″
4-48 (NF) 48 13/16″ #42 / 3/32″ .0935″
5-40 (NC) 40 13/16″ #38 .1015″
5-44 (NF) 44 13/16" #37 .1040"
6-32 (NC) 32 13/16″ #35 / 7/64″ .1100″
6-40 (NF) 40 13/16″ #33 .1130″
8-32 (NC) 32 13/16″ #29 .1360″
8-36 (NF) 36 13/16″ #29 .1360″
10-24 (NC) 24 13/16″ #25 .1495″
10-32 (NF) 32 13/16″ #21 .1590″
12-24 (NC) 24 13/16″ #16 .1770″
12-28 (NF) 28 13/16″ #14 .1820″
