TiALN Inserts - [CCMT-060204]

 Carbide inserts to suit our Lathe Turning Tools and Boring Bars

Aprica Carbide Inserts Made in Taiwan - High Grade Titanium Nitride (85RC)

Smaller Boring Bars: 8, 10 & 12MM Shank - CLICK HERE

What is TIAlN?

A major upgrade to our previous TIN Coated inserts which were upto 60RC. Titanium Aluminium Nitride, forms a hard aluminium oxide layer in hot (> 800ºC), dry machining applications. This further reflects the heat back into the chip and away from the tool and workpiece. Greater ductility makes it a good choice for interrupted cuts. Increased production levels at higher feeds and speeds and longer tool life in high heat applications are the primary benefits.

Applications: Excellent for milling and drilling of high strength steels, hard die steels, and high temperature alloys, including nickel base & titanium (chip classes 120 & 140) where high heat is generated and chipping is a problem.

These inserts are priced as per insert or you can buy our Pack Saver which gives you a small discounted price if buying packs of 10.

Please note these are high grade inserts designed to give our customers the best results when in use.
